Product Details:
Payment & Shipping Terms:
|
| Power Source: | Electric | Type: | Water Source Heat Pump |
|---|---|---|---|
| Storage / Tankless: | instantaneous heater | Use: | Domestic use and commercial use |
| Function: | Heating +cooling | Power supply: | 220V/1PH/50HZ |
| Max Hot Water Temperature: | 55-60C | Cooling capacity: | 5.8kw |
| High Light: | |||
Rate heating working condtion: heat souce side heat exchanger inlet water temp 15℃,
Hot water side heat exchanger beginning of temp 15℃,end of temp 60℃
| Name:Geothermal heat pump/Water source heat pump(Heating and cooling) | |||||
| Model | Unit | FWC-02 | |||
| Rated heating | Heating capacity | kw | 7 | ||
| BTU/h | 22891 | ||||
| Input power | kw | 1.6 | |||
| Input current | A | 8 | |||
| COP | kw/kw | 4.4 | |||
| Rated cooling | Rated cooling capacity | kw | 5.8 | ||
| BTU/h | 19624.5 | ||||
| Rated input power | kw | 1.2 | |||
| Rated input current | A | 6 | |||
| EER | kw/kw | 4.8 | |||
| Max running current | A | 10.5 | |||
| Power source | V/Hz | 220-240V/50Hz | |||
| Nosie level | dB(A) | ≤50 | |||
| Dimension | w*d*h | mm | 725*620*595 | ||
| Weight | kg | 80 | |||
| Precision of temp controll | ±2 | ||||
| Controller | Type | Multi-color backlight LCD, Can accept panel buttons and infrared remote control | |||
| Main function | Working mode control, independent working temperature setting, status display, timer start and stop machine Settings, key lock function, muti-color backlight selection, etc | ||||
| Refrigeration circulation structure | Throttle type | External equalizer thermal expansion valve | |||
| Refrigeration | Type | R410A/R417A/R407C | |||
| Compressor | Type | Hitachi | |||
| Qty | Piece | 1 | |||
| Water source side heat exchange | Type | plate heat exchanger | |||
| Water flow | m3/h | 0.6 | |||
| Water pressure drop | kPa | 10 | |||
| Pipe size | Inch | 3/4 | |||
| Water side max working pressure | kPa | 1000 | |||
| Water chiller heat exchanger | Type | plate heat exchanger/tube in shell heat exchanger | |||
| Water flow | m3/h | 1 | |||
| water pressure drop | kPa | 10 | |||
| Pipe size | Inch | 3/4 | |||
| Water side max working pressure | kPa | 1000 | |||
| Refrigeration system | Too high gas temperature protection,high pressure protection, low pressure protection, sensor fault protection | ||||
| Compressor delay start protection, phase sequence protection, smoke and fire protection | |||||
| Water source system | Water temperature protection, water flow protection, heat exchanger antifreeze protection, standby low temperature protection,Leakage protection | ||||
Rate heating working condtion: heat souce side heat exchanger inlet water temp 15℃,
Hot water side heat exchanger beginning of temp 15℃,end of temp 60℃
